Mikrotik SXTSQ-5AX Wi-Fi 6 CPE | 16 dBi Antenna

 Key Features

Wi-Fi 6 Performance

• Supports 5 GHz Wi-Fi 6 (802.11ax) for improved spectral efficiency, throughput, and multi-device performance vs older standards.

• Maximum wireless data rates up to ~1200 Mbps in the 5 GHz band.

High-Gain Directional Antenna

• Built-in 16 dBi directional antenna boosts range and link stability.

• Effective for long-range links: tested about ~3 km in dense, high-interference urban use and over 10 km in clear line-of-sight scenarios.

Flexible Deployment Modes

• Includes a RouterOS v7, Level 4 license, enabling operation as a CPE client or as a wireless Access Point (AP).

• Supports point-to-multipoint or multipoint-to-client infrastructure configurations.

Hardware & Connectivity

• Dual-core ARM CPU (IPQ-5010 @ 800 MHz) with 256 MB RAM and 128 MB storage for robust performance.

• One Gigabit Ethernet port (10/100/1000 Mbps) with Passive PoE input (12–28 V) for simplified outdoor installation with data + power over a single cable.

• Max power consumption ~6 W, and passive cooling.

Rugged Outdoor Design

• IP55-rated weatherproof housing protects against dust and water — ideal for pole, mast, or rooftop installs.

• Flexible mounting options include hose clamp slots for various orientations, even horizontal railings.

• Operates in extreme environments (-40 °C to +70 °C).

Included Accessories

• PoE Injector

• Power Adapter (commonly 24 V / 0.38 A)

• Hose Clamp for mounting

• Manufacturer warranty typically included.

Use-Case Versatility

This unit fits a range of outdoor wireless networking needs:
 WISP subscriber CPE connecting to remote base stations
 Long-range wireless bridges between locations
 Outdoor wireless AP for coverage expansion
 Temporary wireless links for events or construction sites.
